Mainly used in emergency generator sets, data centers, wind power industry, uninterruptible power supply (UPS), energy storage equipment, test equipment, electric power and other load test occasions of pseudo simulation load test.
》》Industrial grade powerful axial fan with low noise and low temperature rise;
》》The original power consumption is made of special alloy resistor material, strict process production and manufacturing, good heat dissipation performance, high stability;
》》The system can be controlled using a host computer, and test functions such as automatic loading can be performed by inputting the test power, and the electrical parameters can be monitored in real time;
》》Different levels of protection designed for different application environments;
》》User-friendly HMI customized to the actual application;
》》Flexible design, customized production to meet customer non-standard requirements;
》》Load Bank Case Material and Coating Process;
》》Cold-rolled steel plate, industrial-grade standard spray coating, with extremely strong moisture, heat and corrosion resistance;
》》According to the requirements of national and military testing standards, two modes can be selected for testing
1：0%-25%-50%-75%-100%-110% or 2：0%-25%-50%-75%-100%-110%-100%-75%-50%-25%-0%Automatic input of segmented loads，Automatic input of segmented loads;
- Ambient Temperature: -10℃—40℃,
daily average temperature ≤ +35℃
- Ambient Humidity: Daily average ≤ 95%,
monthly a- verage ＜ 90%
- Altitude: ＜ 2000m
- Power Factor: 0.8-1.0
- Test Voltage: AC 400/230V 50Hz
- Error Rate: ≤ ±3%
- Working Mode: Continuous operation
- Load Characteristics: Pure resistive load (inductive load optional)
- Control Power Supply: AC 220V
- Fan Power Supply: AC 400V, three-phase
- Cooling Method: Forced air cooling
- Monitoring Method: Upper computer software monitoring
